Dyne Levels Necessary for Strong Surface Adhesion

The chart below provides suggested dyne levels for successful surface preparation and bonding results considering the intended process, substrate and media.

Process Pad/Screen Printing Offset Printing Coating/Laminating
Material/Ink Solvent Water UV Solvent Water UV Solvent Water UV
LDPE 38-44 42-48 46-60 38-40 38-44 40-50 38-45 42-50 48-56
HDPE 38-44 42-48 46-56 38-40 38-44 38-50 38-44 42-50 48-56
PET 38-44 48-60 44-62 40-46 38-44 38-50 42-48 42-60 48-56
PP 38-44 42-48 44-60 38-40 38-44 40-50 38-44 42-50 48-56
PVC 38-44 42-48 42-60 38-40 38-44 38-44 38-45 40-48 48-56
EPDM N/A N/A N/A N/A N/A N/A 42-50 44-56 48-56
EVA 38-44 42-48 42-60 38-40 38-44 38-50 38-44 42-50 48-56

Request for Quote for Dyne Pens & Dyne Ink

To inquire about purchasing Dyne Pens or Dyne Ink please fill out the form below. We will email you with a quote within one to two business days. Thank you!

This field is for validation purposes and should be left unchanged.
Name
Address
38 Dyne Pens - Dyne Pens are available in 38 dynes/cm. They are a marker style pen with red dyne ink and are sold in packs of 10. Please enter the quantity of packs you wish to have quoted below.
Dyne Pen Kit - The kits are sold with 10 bottles of blue dyne ink ranging from 34-56 dynes/cm. Bottles contain 30 ml of dyne solution and are fitted with a bottle cap brush. A hard shell and foam lined case protect contents. Please enter the quantity of kits you would like to have quoted below.
Individual Bottles of Dyne Ink - Individual bottles of 30 ml dyne ink are available in even numbered dynes/cm from 34 to 70 dynes. Please enter the dyne level and quantity you wish to have quoted below.
